BV145pocket

BV145pocket is the new V-Lock battery pack from BLUESHAPE with a miniaturized pocket form factor.

The battery pack is based on the 21700 Li-Ion cell format, that offer improved efficiency thanks to a multi tab construction that reduces the internal impedance, ideal for high drain applications.

The battery pack integrate an advanced BMS system with wireless connectivity for real time battery monitoring and offer various auxiliary power outlet such as a double bidirectional D-Tap and a powerful bidirectional USB-c PD. The GRANITE SMART remote connectivity, unique in the industry, completes the impressive array of features of this battery pack.

With a capacity within the IATA limitations, it can be transported in the carry-on luggage, max 2pcs per passenger.

Available: October 2024

• Extremely compact form factor: only 77mm x 104mm x 56.9mm thick (3.03" x 4.09" x 2.24")
• Light Weight: 0.71Kg (1.56lbs)
• GRANITE construction, robust, shockproof and IP54
• 2x Auxiliary D-Taps (nominal 14.4V) provide maximum power, up to the battery permissible current draw and can be used as a charging inlet
• 1x USBC-PD 5V~20V up to 100W bi-directional:
• useful to power an array of devices such as camera, laptop, or any USB-C PD powered film making device from 5 to 20V
• can be used to charge the battery from any USB-C power supply
• Two 4x RGB LED arrays located on both sides of the battery to guarantee improved visibility, even if the battery is installed upside down on a stabilizer or other devices.
• The LEDs are activated by touch-sensitive switches that allow for several unique functions such as setting the LEDs to always on for an immediate and remote glance at the battery charge status during use, or varying the intensity of the LEDs according to the needs of the shooting environment.
• The new GRANITE SMART wireless connectivity boosts the usage in the field: compatible with most smartphone and tablets, connects immediately out of the box and helps to control all the batteries in real time during use without lengthy pairing operations
• The USB-C output is also equipped for the useful and unique personal SMARTMon function that provides each user with the ability to interface with their battery via a simple USB-C data cable to monitor and control its functions in direct connection with our customer service, receive updates and implement a personal fleet management
• Nominal Voltage: 14.4V
• Voltage range: 10.0V ~ 16.8V
• Nominal Capacity: 9.9Ah, 145Wh
• Max. discharge current: 16A (20A short peaks)
