BV180two

Home  V-LOCK BATTERIES   GRANITE Two
BV180two

GRANITE Shock-Proof Construction

BV180two

GRANITE LINK Wi-Fi connectivity

BV180two

IP54 Rainproof

BV180two

App control

BV180two

Long-lasting battery

Specifications

  • GRANITE LINK, Wi-Fi enabled remote control
  • 2 Auxiliary D-Taps (nominal 14.8V) provide max 5A with independent overload protection. Left hand side D-Tap with independent overload protection. Right hand side D-Tap is direct and can be used as a charging inlet
  • GRANITE construction, robust, shockproof and IP54 certified
  • Enhanced contact protection for safer air transport
  • Nominal Voltage: 14.8V
  • Voltage range: 10.8V ~ 16.8V
  • Nominal Capacity: 12.0Ah, 180Wh
  • Max. discharge current: 9A
  • Medium size and lightweight
  • Size: 171 x 95 x 53mm (6.73" x 3.74" x 2.08")
  • Weight: 1.19Kg (2.62lbs)

Downloads

Operating Manuals

GRANITE TWO V-Lock series operator manual

Certificate

CE Declaration of Conformity for GRANITE TWO and GRANITE MINI batteries

Material Safety Data Sheet for all BLUESHAPE batteries v1.9

UN38.3 IATA Transport declaration for BV180

Ingress Protection certificate for BV180 against dust and water

Application Notes

2014 update of the IATA air transport regulations for rechargeable lithium ion, with a dedicated focus on BLUESHAPE batteries range
